Kubernetes Problems Demystified: Troubleshooting and Fixing Common Errors



Table of Contents:


Master Kubernetes troubleshooting with this guide to resolve common issues and keep your clusters running smoothly and efficiently!

Overview

Kubernetes is an open-source platform for automating containerized applications' deployment, scaling, and management. While it offers great flexibility and scalability, managing Kubernetes clusters is not without its challenges. Common issues can arise when interacting with pods, services, networking, storage, and more. In this blog, we will explore several common Kubernetes issues, give real-world examples, and provide practical fixes to help you keep your clusters running smoothly.

Kubernetes Common Errors and Fixes
Kubernetes Common Error and Fixes

Common Kubernetes Issues and Fixes

ImagePullBackOff - Failed to Pull Container Image:

Description:

The ImagePullBackOff error occurs when Kubernetes cannot pull a container image from the registry, often due to incorrect image names, authentication issues, or unavailable images.

Common Causes:

  • The container image doesn’t exist.

  • The image tag is incorrect.

  • Docker Hub or a private registry authentication failure.

Example Scenario:

Imagine you have a pod configured to pull an image from Docker Hub:

apiVersion: v1
kind: Pod
metadata:
  name: my-app
spec:
  containers:
  - name: my-container
    image: non-existant-image:latest

Here, Kubernetes fails to pull non-existant-image:latest, resulting in the error ImagePullBackOff.

How To Fix It:

  • Check pod events to see what’s going wrong:

kubectl describe pod <pod-name>
  • Check the Image Name and Tag: Ensure that the image name and tag are correct. A typo or outdated tag could be the culprit.

docker pull <image>:<tag>
  • Verify Image Availability: Make sure the image exists in the registry. If using a private registry, ensure the image is pushed correctly.

  • Credentials for Private Registries: If using a private registry, ensure you have provided the correct credentials. You can use Kubernetes Secret to store Docker registry credentials:

kubectl create secret docker-registry regcred --docker-server=DOCKER_REGISTRY_SERVER --docker-username=DOCKER_USERNAME --docker-password=DOCKER_PASSWORD --docker-email=DOCKER_EMAIL

CrashLoopBackOff - Pods Keep Restarting:

Description:

A CrashLoopBackOff error indicates that the pod's container keeps crashing and restarting repeatedly. This is often due to application errors or misconfigurations in the pod.

Common Causes:

  • The application within the container is failing due to an error.

  • Environment variables are either missing or incorrectly configured.

  • The allocated resources are insufficient.

  • Required dependencies are unavailable (e.g., a necessary database cannot be accessed).

Example Scenario:

A pod running a Node.js application experiences an error during startup, causing it to exit unexpectedly.

apiVersion: v1
kind: Pod
metadata:
  name: node-app
spec:
  containers:
  - name: node-container
    image: node:14
    command: ["node", "app.js"]

If the app.js script contains a fatal error, the container will crash, leading to a CrashLoopBackOff state.

How to Fixe It:

  • Check pod logs to spot the root cause:

kubectl logs <pod-name> -n <namespace>
  • Describe the pod to see detailed event information:

kubectl describe pod <pod-name> -n <namespace>
  • Verify that all dependencies are up and running before the pod starts.

  • Adjust resource limits in your deployment YAML:

resources:
  requests:
    memory: "64Mi"
    cpu: "250m"
  limits:
    memory: "128Mi"
    cpu: "500m"
  • Readiness and Liveness Probes: Define health checks to ensure the application can recover gracefully. Use readiness and liveness probes to detect and restart unhealthy containers.

livenessProbe:
  httpGet:
    path: /healthz
    port: 8080
  initialDelaySeconds: 3
  periodSeconds: 3

ErrImagePull: Kubernetes Can’t Pull the Image:

Description:

Kubernetes isn’t able to pull the container image—similar to ImagePullBackOff.

Common Causes:

  • The image name or tag might be wrong.

  • The image is private and needs proper authentication.

Example Scenario:

You have deployed a microservice application on a Kubernetes cluster. The application relies on a custom Docker image that you've pushed to a private container registry. However, after deploying the pod, you notice that the container fails to start, and Kubernetes throws an error indicating ErrImagePull.

How to Fix It:

  • Double-check that the image exists in the registry.

  • Ensure you have authenticated correctly by creating the necessary secret

Pod Stuck in Pending State

Description:

A pod remains in the Pending state and never starts.

Common Causes:

  • Insufficient node resources.

  • Taints and tolerations blocking scheduling.

  • Mismatched node selectors.

How to Fix It:

  • Describe the pod to check for error messages:

kubectl describe pod <pod-name>
  • Check your available nodes:

kubectl get nodes
  • Inspect node taints that might be keeping the pod from scheduling:

kubectl describe node <node-name>
  • Ensure you’re using the right node selectors or tolerations in your YAML:

tolerations:
     - key: "node-role.kubernetes.io/master"
       operator: "Exists"
       effect: "NoSchedule"

Node Not Ready

Description:

A node is marked as NotReady, so no new pods can be scheduled on it.

Common Causes:

  • Network connectivity issues.

  • Disk pressure.

  • Insufficient CPU or memory.

How to Fix It:

  • Check the node status:

kubectl get nodes
  • Describe the node for more detailed info:

kubectl describe node <node-name>
  • Review the Kubelet logs on the node:

journalctl -u kubelet -f
  • Restart the Kubelet:

systemctl restart kubelet
  • Verify network connectivity between the node and the master.

Pod Network Issues:

Description:

Network connectivity problems in Kubernetes can manifest as failures in pod-to-pod communication, external access issues, or DNS resolution problems.

Example Scenario:

You have a pod with a service that is unable to reach another pod, even though both are part of the same namespace.

How To Fix It:

  • Check Pod Networking Configuration: Ensure that your pod networking setup (such as CNI plugin) is properly configured. Misconfigured network plugins (like Calico or Flannel) can cause networking issues.

  • Inspect Pod Network Policies: If network policies are defined, ensure they aren't restricting access between pods. Network policies can limit communication between pods in specific namespaces or based on labels.

apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: allow-frontend-to-backend
spec:
  podSelector:
    matchLabels:
      app: backend
  ingress:
    - from:
        - podSelector:
            matchLabels:
              app: frontend

Persistent Volume (PV) Issues:

Description:

Kubernetes provides persistent storage through Persistent Volumes (PVs) and Persistent Volume Claims (PVCs). Issues arise when PVs are not properly provisioned, mounted, or released.

Example Scenario:

A pod cannot mount a PVC, and the status shows Pending:

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: my-pvc
spec:
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 10Gi

The associated PV might be incorrectly configured or unavailable.

Fixes:

  • Check PV and PVC Status: Verify that the PV and PVC are correctly bound using kubectl get pv and kubectl get pvc.

  • Check Storage Class Configuration: If using dynamic provisioning, ensure that the appropriate storage class is defined in both PVC and PV. storageClassName: standard

Resource Exhaustion:

Description:

Resource exhaustion occurs when a node or pod runs out of CPU, memory, or disk space, leading to failures or poor performance.

Example Scenario:

Your cluster nodes are running out of memory, causing pod eviction and disruption.

Fixes:

  • Check Resource Usage: Use kubectl top pod to check the resource consumption of your pods. If a pod is consuming too much memory or CPU, you may need to adjust resource requests and limits.

  • Node Resource Utilization: Monitor node resource usage via kubectl top node to identify which nodes are over-utilized.

  • Eviction Policies: Kubernetes will evict pods when resources are scarce. You can modify eviction thresholds or use PodPriority to avoid eviction of critical pods.

Conclusion

Kubernetes offers a powerful orchestration platform, but like any complex system, it can encounter a range of issues. By understanding common problems such as ImagePullBackOff, CrashLoopBackOff, and network or resource-related errors, you can quickly identify and address issues to ensure your clusters run efficiently. Leveraging tools like logs, resource metrics, and Kubernetes built-in health checks can help you pinpoint the root causes and take appropriate actions.


By following the troubleshooting steps outlined in this blog, you can enhance your Kubernetes management skills and minimize downtime in production environments. Always ensure that your system is properly configured, monitored, and maintained for optimal performance.
